The Reason Why Choose Square Head Bolts With Collar From AYA FASTENERS
Dec 09, 2022
There are many situations when you need to fasten items and ensure that their multiple components won't just fall off. Which is buying Square Head Bolts With Collar is a great idea, since these can help provide strength and assistance, while also maintaining a rustic, unique look. The added collar is designed to boost the strength of the bolt even further while making sure the items you fastened will stay in place at all times.
Square Head Bolts With Collar
Square Head Bolts
Square Bolts
Square Head Bolts With Collar features
These square head bolts with collar are also named galvanized square head bolts and they are made out of carbon steel. They have a property class of 4.6~12.9, and the diameter can range from M5, and M6 up to M24. You have multiple options, which makes the Square Head Bolts With Collar an ideal option, especially if you want to cover different applications based on your needs.
The head type of these square head bolts is a square head, and the drive type is an external square. What makes the square head bolts with collar great however is that the thread is free of burrs, and you don't have to worry about the bolt slipping in any way. So the rotation process is perfect, and the results that you can obtain are nothing short of incredible.
Another thing to consider is that such bolts also have different finishes. These finishes can range from nickel plating to black oxide, and zinc plating, but also phosphating, dacromet and organic, among others. Thanks to the different finishes, you will be able to ensure any square head bolt you use will seem organically added to the project and won't stand out.
All square head bolts with collar are flat and smooth, they also maintain a very high hardness level. In doing so, you maintain practicality while also keeping the right shape. These bolts will not deform, as long as you stick to the weight limits and guidelines. AYA Fasteners is able to fully customize the Square Head Bolts you need, which means you can easily have the right bolts done for your particular business. In doing so, you get to save a lot of time, and the results are stunning every time.
| Thread Size d | M5 | M6 | M8 | M10 | M12 | M16 | M16 | M20 | M20 | M24 | ||||
| P | Pitch | 0.8 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | 2.5 | 3 | |||
| b | +2P,0 | L≤125 | 16 | 18 | 22 | 26 | 30 | 38 | 38 | 46 | 46 | 54 | ||
| L＞125 | - | - | - | 32 | 36 | 44 | 44 | 52 | 52 | 60 | ||||
| c | min | 1.88 | 1.88 | 1.88 | 2.88 | 2.88 | 3.85 | 3.85 | 4.85 | 4.85 | 5.85 | |||
| max | 2.12 | 2.12 | 2.12 | 3.12 | 3.12 | 4.15 | 4.15 | 5.15 | 5.15 | 6.15 | ||||
| dc | max=nominal size | 9.5 | 10.5 | 13.5 | 16.5 | 19.5 | 25 | 25 | 31 | 31 | 36 | |||
| min | 8.92 | 9.8 | 12.8 | 15.8 | 18.66 | 24.16 | 24.16 | 30 | 30 | 35 | ||||
| ds | max=nominal size | 5 | 6 | 8 | 10 | 12 | 16 | 16 | 20 | 20 | 24 | |||
| min | 4.82 | 5.82 | 7.78 | 9.78 | 11.73 | 15.73 | 15.73 | 19.67 | 19.67 | 23.67 | ||||
| k | min | 6.82 | 7.82 | 9.82 | 12.78 | 14.78 | 19.74 | 19.74 | 24.74 | 24.74 | 27.74 | |||
| max | 7.18 | 8.18 | 10.18 | 13.22 | 15.22 | 20.26 | 20.26 | 25.26 | 25.26 | 28.26 | ||||
| s | max=nominal size | 5 | 6 | 8 | 10 | 13 | 16 | 17 | 21 | 22 | 24 | |||
| min | 4.82 | 5.82 | 7.78 | 9.78 | 12.73 | 15.73 | 16.73 | 20.67 | 21.67 | 23.67 | ||||
| e | max=nominal size | 6.5 | 8 | 10 | 13 | 17 | 21 | 22 | 27 | 28 | 32 | |||
| min | 5.92 | 7.42 | 9.42 | 12.3 | 16.3 | 20.16 | 21.16 | 26.16 | 27.16 | 31 | ||||
Square Head Bolts With Collar: applications
Where can you use these square head bolts? The applications will vary quite a lot, and they range from manufacturing to cars, trains, wind turbines, logistics, and many others. It can be a great solution for chemical manufacturing, mining, oil refineries, and utilities. The Square Head Bolts With Collar is designed to help deliver efficiency, great quality, and incredible value for the money.
Why should you use these Square Head Bolts?
The square head bolts with collar are available in different grades, finishes, and sizes. On top of that, all these bolts are externally threaded in order to deliver better efficiency, while also offering stellar quality and value for the money. These bolts also come with a warranty, and they are made from durable materials. So if you're looking for some of the best square head bolts with collar, choose AYA Fasteners today and gain access to incredible quality and value for money!
AYA FASTENERS is one of the most reputable leading fasteners manufacturers and suppliers in China, we focus on assembly and fastening materials, supplying global customers with high-quality screws, bolts, washers, and nuts products over 20 years.
AYA has been deeply involved in the Fastener industry with a single-minded and dedicated attitude, devoted itself to providing our customers with more industry-specific, professional, standardized, and precise Fastener solutions. If you want more information, please contact AYA FASTENERS for the details.
