Wing Bolt Butterfly Screw
Standard: JIS B 1184
Thread Type: Coarse Thread
Commodity: Wing Bolt Butterfly Screw
Also Named: Butterfly Wing Screws
Material: Carbon Steel
Diameter: M2、M2.2、M2.5、M3、M4、M5、M6、M8、M10、M12、M14、M16、M18、M20、M22、M24
Finish: Plain, Black Oxide, Zinc Plated, Hot Dipped Galvanized, Oxidation, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated
Wing Form: Round
Alternative Standard: ANSI/ASME B 18.17
MOQ: 1000kgs
Lead Time: 30 to 60 days
Product Introduction
AYA Fasteners (Hebei) Co., Ltd. is one of the most experienced manufacturers and suppliers of wing bolt butterfly screw in China. Please feel free to buy high quality wing bolt butterfly screw made in China here from our factory. For price consultation, contact us.
As a global supplier of customized fastening solutions, AYA's service process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.
PRODUCT DESCRIPTION
| Product Name | Wing Bolt Butterfly Screw |
| Also Named | Butterfly Wing Screws |
| Material | Carbon Steel |
| Standard | JIS B 1184 |
Diameter | M2、M2.2、M2.5、M3、M4、M5、M6、M8、M10、M12、M14、M16、M18、M20、M22、M24 |
| Finish | Plain, Black Oxide, Zinc Plated, Hot Dipped Galvanized, Oxidation, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated |
| Thread Type | Coarse Thread |
Wing Form | Round |
| Alternative Standard | ANSI/ASME B 18.17 |
DIMENSIONS TABLE
| Nominal Diameter d | Pitch P | dk min | k min | H | h1 | h2 | n | ||
| max | min | max | max | max | min | ||||
| M2 | 0.4 | 4 | 2 | 7.5 | 4.5 | 2.5 | 3 | 13.5 | 10.5 |
| M2. 2 | 0.4 | ||||||||
| M2. 5 | 0. 45 | 5 | 3 | 9.5 | 6.5 | 2.5 | 3 | 17.5 | 14.5 |
| M3 | 0.5 | ||||||||
| M4 | 0.7 | 7 | 4 | 11.5 | 8.5 | 3 | 4 | 21.5 | 18.5 |
| M5 | 0.8 | 8.5 | 5 | 13.5 | 10.5 | 3.5 | 4.5 | 26.5 | 23.5 |
| M6 | 1 | 10.5 | 6 | 17.5 | 14.5 | 4 | 5 | 34 | 30 |
| M8 | 1.25 | 14 | 8 | 21.5 | 18.5 | 4.5 | 5.5 | 42 | 38 |
| MIO | 1.5 | 18 | 10 | 26.5 | 23.5 | 5.5 | 6.5 | 52 | 48 |
| N12 | 1.75 | 22 | 12 | 31.5 | 28.5 | 7 | 8 | 62 | 58 |
| Ml 4 | 2 | 26 | 14 | 37 | 33 | 8 | 9 | 72 | 68 |
| Ml 6 | 2 | ||||||||
| N18 | 2.5 | 30 | 16 | 42 | 38 | 8 | 10 | 82 | 78 |
| M20 | 2.5 | 34 | 18 | 47 | 43 | 9 | 11 | 92.5 | 87.5 |
| N22 | 2.5 | 38 | 20 | 52 | 48 | 10 | 12 | 102.5 | 97.5 |
| M24 | 3 | 43 | 22 | 58 | 54 | 11 | 13 | 114.5 | 109.5 |
PRODUCT DETAILS
PRODUCT ADVANTAGES
ADVANTAGES OF Wing Bolt Butterfly Screw
1. It can be installed easily and quickly simply with a hand.
2. It is made from high-quality steel products that bring a long service life with low-cost maintenance in the future.
3. Quite moderate torque is required for fastening and connection.
4. It's quite durable due to its high-standard raw materials and superior surface treatment.
5. AYA has built over 20 warehousings worldwide to deliver products quickly and conveniently.
6. AYA has manufactured this item for over 10 years and has enough experience to deal with kinds of fastening issues.
QUALITY INSPECTION
PACKAGING & CONTAINER LOADING
USAGE SCENARIOS
WHY CHOOSE AYA?
