Metal Lock Nut

Standard: ISO 7042
Thread Type: Coarse Thread
Commodity: Metal Lock Nut
Also Named: Hexagon Lock Nut
Material: Carbon Steel
Property Class: 5、8、10、12
Diameter: M5、M6、M8、M10、M12、(M14)、M16、M20、M24、M30、M36
Finish: Plain/ Black Oxide/ Zinc Plated/ Thick-Film Passivated(ZSML)/ Zinc Flake, Silver(ZFSHL)/ Hot Dipped Galvanized/ Organic/ Geomet/ Dacromet/ Phosphating/ Cadmium Electroplate/ Nickel Plated
Drive Type: External Hex
Alternative Standard: ISO 7719, ISO 7720, DIN 980(V), DIN 6925, ISO 10513, DIN 980(M)
MOQ: 1000kgs
Lead Time: 30 to 60 days

Send Inquiry

Product Introduction

AYA Fasteners (Hebei) Co., Ltd. is one of the most experienced manufacturers and suppliers of metal lock nut in China. Please feel free to buy high quality metal lock nut made in China here from our factory. For price consultation, contact us.

As a global supplier of customized fastening solutions, AYA's service process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.

PRODUCT DESCRIPTION

Product Name	Metal Lock Nut
Also Named	Hexagon Lock Nut
Material	Carbon Steel
Standard	ISO 7042
Property Class	5、8、10、12
Diameter	M5、M6、M8、M10、M12、(M14)、M16、M20、M24、M30、M36
Finish	Plain/ Black Oxide/ Zinc Plated/ Thick-Film Passivated(ZSML)/ Zinc Flake, Silver(ZFSHL)/ Hot Dipped Galvanized/ Organic/ Geomet/ Dacromet/ Phosphating/ Cadmium Electroplate/ Nickel Plated
Drive Type	External Hex
Thread Type	Coarse Thread
Alternative Standard	ISO 7719, ISO 7720, DIN 980(V), DIN 6925, ISO 10513, DIN 980(M)

DIMENSIONS TABLE

Metal Lock Nuts 2D

Screw Thread d		M5	M6	M8	M10	M12	(M14)	M16	M20	M24	M30	M36
Screw Thread d		M5	M6	M8	M10	M12	(M14)	M16	M20	M24	M30	M36
P	Pitch	0.8	1	1.25	1.5	1.75	2	2	2.5	3	3.5	4
d_a	max	5.75	6.75	8.75	10.8	13	15.1	17.3	21.6	25.9	32.4	38.9
d_a	min	5	6	8	10	12	14	16	20	24	30	36
d_w	min	6.88	8.88	11.63	14.63	16.63	19.64	22.49	27.7	33.25	42.75	51.11
e	min	8.79	11.05	14.38	17.77	20.03	23.36	26.75	32.95	39.55	50.85	60.79
h	max	5.1	6	8	10	13.3	14.1	16.4	20.3	23.9	30	36
h	min	4.8	5.4	7.14	8.94	11.57	13.4	15.7	19	22.6	27.3	33.1
s	max	8	10	13	16	18	21	24	30	36	46	55
s	min	7.78	9.78	12.73	15.73	17.73	20.67	23.67	29.16	35	45	53.8
m_w	min	3.52	3.92	5.15	6.43	8.3	9.68	11.28	13.52	16.16	19.44	23.52

PRODUCT DETAILS

Metal Lock Nuts details

PRODUCT ADVANTAGES

Metal Lock Nuts advantage

ADVANTAGES OF Metal Lock Nut

1. Metal lock nut, full thread through thread deformation to play a locking role.

2. Hebei Sinostar offers a variety of surface treatments including plain, black oxide, zinc plated, dacromet, phosphating, etc.

3. The normal force generated by the locking nut is much greater than that of the ordinary standard nut, which has great anti-loosening and anti-vibration ability.

4. The metal lock nut has strong abrasion resistance and shear resistance. Because the pressing force is evenly distributed on the thread surface of each tooth, the nut can better solve the problems of thread wear and shear deformation.

5. The locking nut has been repeatedly tightened and disassembled. The advantage of the all-metal locking nut is that its locking force still does not decrease and the original locking effect can be maintained.

QUALITY INSPECTION

Quality Check-AYA Fasteners

PACKAGING & CONTAINER LOADING

Packing-AYA Fasteners

USAGE SCENARIOS

Usage-AYA Fasteners

WHY CHOOSE AYA?

AYA provides exclusive services to 1000+ members from all over the world every year, with a unique chain service solution system, you only need to click the mouse to get exclusive fastening solution and enjoy door-to-door services.
