AYA FASTENERS Guide | Dog Point Hex Head Screw Main Features and Advantages

Dog Point Hex Head Screws are an excellent type of screw available in the market. They are ideal for various types of purposes, like other screws available in the market. Dog point hex head screws are socket set screws that come in two varieties. One is a full-dog point, and another is a half-dog point. The protruded tip characterizes both screws. Half dog point screws come with a shorter tip than dog point screws to work in limited clearance applications. However, full dog point screws have the ability to work for a wide variety of purposes.

These screws are industrial fasteners that have the ability to hold more than one object at a time, in a place, and securely. They are designed to insert in a mechanical hole, flat, or slot against a shaft as a permanent setting. Dog point hex head screws can be built with any kind of material to suit your needs or requirements. They are also available in most sizes.

















AYA Dog Point Hex Head Screws Dimension Table(DIN 561)



Screw Thread d		M6	M8	M10	M12	M16	M20	M24	M30	M36	M42	M48	M56
P	Pitch（Coarse thread）	1	1.25	1.5	1.75	2	2.5	3	3.5	4	4.5	5	5.5
	Pitch（Fine thread）	-	-	-	-	-	2	2	2	3	3	3	3
a	max	3	3.75	4.5	5.25	6	7.5	9	10.5	12	13.5	15	16.5
da	max	6.8	9.2	11.2	13.7	17.7	22.4	26.4	33.4	39.4	45.6	52.6	63
dp	max=nominal size	4	5.5	7	8.5	12	15	18	23	28	32	38	45
	min	3.82	5.32	6.78	8.28	11.73	14.73	17.73	22.67	27.67	31.61	37.61	44.61
e	min	8.79	11.05	14.38	17.77	19.92	26.75	33.53	39.98	51.28	61.31	72.61	83.91
k	nominal size	5	6	7	9	11	14	17	21	25	30	34	40
	min	4.85	5.85	6.82	8.82	10.79	13.79	16.79	20.74	24.74	29.74	33.69	39.69
	max	5.15	6.15	7.18	9.18	11.21	14.21	17.21	21.26	25.26	30.26	34.31	40.31
kw	min	3.4	4.1	4.8	6.2	7.6	9.7	11.8	14.5	17.3	20.8	23.6	27.8
s	max=nominal size	8	10	13	16	18	24	30	36	46	55	65	75
	min	7.78	9.78	12.73	15.73	17.73	23.67	29.67	35.38	45.38	54.26	64.26	74.26
z	min=nominal size	3	4	5	6	8	10	12	15	18	21	24	28
	max	3.25	4.3	5.3	6.3	8.36	10.36	12.43	15.43	18.43	21.52	24.52	28.52
①, Material: a)Steel, Property class(material): 14H, 22H Standard DIN ISO 898-5; b)Stainless steel, Property class(material): A2-50 Standard DIN ISO 3506; c)Non-ferrous metal, Property class(material): CuZn=CU2 or CU3 Standard DIN EN 28839, at the choice of the manufacturer





Main Features of Dog Point Hex Head Screws

Dog Point Hex Head Screw has the ability to suit each need in the market. Moreover, they come with attractive features, making them a perfect choice for most industries. Below is the list of top features of dog point hex head screws:

● Strength - Dog point hex head set screw provides a strength of 45H because they are built from materials like alloy steel.
● Hardness - Dog point hex head screw comes with a hardness of 5g6g.
● Excellent part grade - It comes with an excellent part grade, an A grade.
● Surface treatment - Dog point hex screw also comes with a surface treatment of black oxide coating and anti-rust oil.

This is not the end of the features of the dog point hex head screws. These screws come with more features apart from the list mentioned above.





Dog Point Hex Head Screws Advantages

Dog Point Hex Head Screw is among the top screws. These screws are very popular due to their advantages. Below are the top advantages of Dog Point Hex Head Screw:

● Easy to use - Anyone can use dog point hex head screws easily. You just need to screw the screws with a screwdriver.
● Tensile strength - Dog point hex head screw provide tensile strength due to its robust material.
● Excellent resistance - Dog point hex head screw also comes with the ability to corrosion and temperature resistance.
● Compression - Dog point hex head screws are specially designed to retain compression for free rotation.

We hope you understand what you can get with the Dog Point Hex Head Screw.





Applications

Dog point hex head screws are built to use for a number of purposes. This is the only reason behind the popularity of these screws. Below is the list of the top application of dog point set screw:

● Dog point hex head screws are used to fasten two objects.
● It is also used to secure gear to the shaft.
● They are also used in successful heavy applications

Regardless of the purpose, these screws are the perfect choice for every use.
