Oval Head Wood Screws

Standard: ANSI/ASME B 18.6.1
Thread Type: Wood Screw Thread
Commodity: Oval Head Wood Screws
Also Named: Bronze Oval Head Wood Screws
Material: Carbon Steel
Diameter: 0#、1#、2#、3#、4#、5#、6#、7#、8#、9#、10#、12#、14#、16#、18#、20#、24#
Finish: Plain, Black Oxide, Zinc Plated, Thick-Film Passivated(ZSML), Zinc Flake, Silver(ZFSHL), Hot Dipped Galvanized, Organic, Geomet, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated
Head Type: Raised Countersunk Head / Oval Head
Drive Type: Cross Drive
Alternative Standard: DIN 7995, ANSI/ASME B 18.6.1, JIS B 1112, JIS B 1135
MOQ: 1000kgs
Lead Time: 30 to 60 days

Send Inquiry

Product Introduction

AYA Fasteners (Hebei) Co., Ltd. is one of the most experienced manufacturers and suppliers of oval head wood screws in China. Please feel free to buy high quality oval head wood screws made in China here from our factory. For price consultation, contact us.

Wood Screws-AYA

As a global supplier of customized fastening solutions, AYA's service process is also as close to customers as AYA's products. From describing needs to follow-up services, AYA will promptly and spare no effort to help customers solve any fastening problems that arise, to eliminate the concern of customers.

PRODUCT DESCRIPTION

Product Name	Oval Head Wood Screws
Also Named	Bronze Oval Head Wood Screws
Material	Carbon Steel
Standard	ANSI/ASME B 18.6.1
Diameter	0#、1#、2#、3#、4#、5#、6#、7#、8#、9#、10#、12#、14#、16#、18#、20#、24#
Finish	Plain, Black Oxide, Zinc Plated, Thick-Film Passivated(ZSML), Zinc Flake, Silver(ZFSHL), Hot Dipped Galvanized, Organic, Geomet, Dacromet, Phosphating, Cadmium Electroplate, Nickel Plated
Alternative Standard	DIN 7983, ASME B 18.6.3, ASME B 18.6.4, ASME B 18.6.5M, JIS B 1122 (O)
Head Type	Raised Countersunk Head / Oval Head
Drive Type	Cross Drive
Thread Type	Wood Screw Thread
Alternative Standard	DIN 7995, ANSI/ASME B 18.6.1, JIS B 1112, JIS B 1135

DIMENSIONS TABLE

Oval Head Wood Screws-2D

d		TPI	dk		k	H		Socket No.	M		N	Slot Depth
d		TPI	max	min	k	max	min	Socket No.	max	min	min	max	min
#0	0. 063	32	0.119	0. 099	0. 035	0. 056	0. 041	0	0. 074	0. 061	0. 018	0. 048	0. 032
#1	0. 073	28	0.146	0.123	0. 043	0. 068	0. 052	0	0. 077	0. 064	0. 018	0. 051	0. 035
#2	0. 085	26	0.172	0.147	0. 051	0. 08	0. 063	1	0.112	0. 099	0. 029	0. 073	0. 057
#3	0. 099	24	0.199	0.171	0. 059	0. 092	0. 073	1	0.124	0.111	0. 03	0. 085	0. 069
#4	0.112	22	0. 225	0.195	0. 067	0.104	0. 084	1	0.136	0.123	0. 03	0. 097	0. 081
#5	0.125	20	0. 252	0. 220	0. 075	0.116	0. 095	2	0.158	0.145	0. 041	0. 089	0. 071
#6	0.133	18	0. 279	0. 244	0. 083	0.122	0.105	2	0.178	0.165	0. 041	0.109	0. 091
#7	0.151	16	0. 305	0. 268	0. 091	0.14	0.116	2	0.189	0.176	0. 041	0.12	0.102
#8	0.164	15	0. 332	0. 292	0.100	0.152	0.126	2	0. 205	0.192	0. 041	0.137	0.119
#9	0.177	14	0. 358	0. 316	0.108	0.164	0.137	2	0. 216	0. 203	0. 042	0.148	0.13
#10	0.193	13	0. 385	0. 340	0.116	0.176	0.148	3	0. 261	0. 248	0. 056	0.147	0.129
#12	0. 215	11	0. 438	0. 389	0.132	0. 200	0.169	3	0. 283	0. 27	0. 057	0.169	0.151
#14	0.242	10	0. 507	0.452	0.153	0. 232	0.197	3	0. 29	0. 277	0. 057	0.177	0.159
#16	0. 263	9	0. 544	0. 485	0.164	0. 248	0. 212	3	0.332	0. 319	0. 057	0. 219	0. 201
#18	0.294	8	0.635	0. 568	0.191	0. 290	0. 249	4	0. 39	0. 377	0. 086	0. 241	0. 223
#20	0. 323	8	0. 650	0. 582	0.196	0. 296	0. 254	4	0. 4	0. 387	0. 086	0. 251	0. 233
#24	0.372	7	0. 762	0. 685	0. 230	0. 347	0. 300	4	0. 41	0. 397	0. 086	0. 262	0. 244

PRODUCT DETAILS

Oval Head Wood Screws details

PRODUCT ADVANTAGES

Oval Head Wood Screws advantage

ADVANTAGES OF Oval Head Wood Screws

1. The decorative rounded top of the screws presents you with a finished appearance. You can insert the screws into countersunk holes.

2. Threads are pressed into material for a highly secure and tight hold. You can drill a small hole to prevent splitting issues.

3. The stainless steel finish has added a level of perfection to the screws. You can fasten objects of different materials like wood, plastic, metal, and fiberglass.

4. The overall design of the oval head screws is highly durable.

5. AYA has an efficient team to deliver these screws on time.

6. AYA guarantees that there will be no flaws in the screw designs.
